5km Drone Security Defense System Detects UAV Detection

The system features 360° coverage, advanced threat warning, precise drone model/identity recognition, and seamless integration with adversarial systems. 5km Drone Security Defense System Detects UAV Detection is suitable for a variety of scenarios including airports, military bases, power plants, government facilities, stadiums, and corporate campuses. It combines real-time detection, intelligent identification, and rapid response capabilities to provide powerful defense capabilities to effectively resist unauthorized drone activities and ensure the safety of highly sensitive environments and large venues.

Send Inquiry

Product Description

5km Drone Security Defense System Detects UAV Detection scans the 700-6300MHz frequency range and detects drones up to 5km away (distance adjustable via antenna). The detector decodes DJI FPV signals, pinpoints pilot position, manages allow/block lists, and provides video feed for visual inspection. The detector has 360° coverage and can quickly connect to jammers to respond to threats quickly, enabling real-time monitoring and intelligent countermeasures in high-security areas.

Product specification

Regular detection range	5km（Good radio environment）
Detection frequency bands	0.7-6.3GHz/ 2.4-2.5GHz/5.15-5.95GHz
Identify Type	FPV Simulation Image Transmission OFDM HD Image Transmission
Detection angle	360°
Sensitivity	Better than -96dBm (FPV signal Bw=6MHz) Better than -90dBm (OFDM signal Bw=20MHz)
Detection distance	＞2km (OFDM)＞4km (FPV 5.8G/2W) (The measured reliable distance when using a 2dBi gain receiving antenna. The actual antenna gain increases by 6dB, and the detection distance can be doubled.)
UART Parameters	115.2kbps/TTL3~5V compatible
Power supply	DC 4.75 ~36V
Power consumption	＜3.5W
Weight	25kg
Volume	330mm x330mm x330mm
Protection grade	IP65
Working temp	-40 ~ +70℃
